Breaking ELM Between Two VCF Instances to Restore a Supported Upgrade Path

Introduction

Most VMware Cloud Foundation upgrade blockers look like lifecycle problems—version mismatches, failed prechecks, or sequencing issues.

This one wasn’t.

The environment was fully functional. Services were healthy. No visible instability. But underneath that, two separate VCF instances were operating in a shared Enhanced Linked Mode (ELM) topology.

That became the blocker.

And it’s important to be clear: this wasn’t accidental. This was a deliberate design that had been implemented when it was supported. The issue surfaced because the platform evolved—and the design didn’t.

What followed wasn’t a patch. It was a controlled teardown of a shared SSO domain and replication topology.

Background

Enhanced Linked Mode in VCF is often misunderstood as a UI-level feature. In reality, it creates a shared identity and replication boundary through:

A common SSO domain
vmdir replication agreements
Shared global permissions and tags
Cross-vCenter authentication dependencies

Historically, joining multiple VCF instances into the same SSO domain was supported.

That changed.

As noted in VCF 4.5 documentation, the ability to join multiple VCF instances to the same SSO domain was deprecated. That effectively makes cross-instance ELM an unsupported topology for modern upgrade paths.

In many environments I’ve worked with, this kind of design persists because it continues to function. The problem only shows up when you try to move forward.

Real-World Scenario

The environment consisted of two sites operating as separate VCF instances:

One site hosting multiple vCenters (management, workload, non-prod)
Another site with its own management and workload vCenters

Despite being separate VCF instances, they were joined into a single SSO domain and linked through ELM.

From an operational standpoint, this created what’s often referred to as a “handcuff topology.”

Everything worked—but nothing was truly independent.

When the upgrade path to a newer VCF version was evaluated, this topology became a hard stop. The environment had to be separated before proceeding.

Technical Analysis

This is where things get interesting.

Breaking ELM isn’t just “unlinking vCenters.” You’re dismantling a shared identity system backed by vmdir replication.

What Actually Existed

Multiple vCenters across two sites shared a single SSO domain
vmdir replication agreements existed across sites
Identity and authentication were fully coupled
Management and workload domains were not cleanly isolated

What Had to Change

The goal was to:

Remove cross-site SSO dependencies
Break replication agreements
Restore independent VCF instance boundaries

This required working directly with:

CMS utilities (vCenter domain management)
vmdir replication tools (vdcrepadmin)
SSO unregister workflows

Execution Details

From an execution standpoint, the process followed a controlled sequence:

1. Environment Preparation

All vCenters were powered down simultaneously
Snapshots were taken across all nodes
DRS was set to manual to prevent movement during the process

One thing that often surprises teams:

If you snapshot a vmdir-based topology, all nodes must be treated consistently. Partial rollback creates replication divergence.

2. CMS-Based Unregistration

From the primary site, the team:

Executed cmsso-util unregister commands
Removed remote vCenter nodes from the SSO domain
Used administrator-level SSO credentials

This effectively detached one site from the shared identity domain.

3. Replication Topology Rebuild

After unregistering nodes:

vdcrepadmin was used to recreate replication agreements
A new ring topology was established for the remaining nodes
Cross-site replication agreements were removed

This step is critical.

Breaking ELM without rebuilding replication properly leaves the environment in an inconsistent state.

4. Site Separation

Post-change:

One site operated independently with its own vCenters
The other site retained its own internal ELM structure
Cross-instance dependencies were fully removed

This is where the architecture returned to a supported model.

Operational Considerations

From an operations perspective, this wasn’t just a technical task—it was a coordinated change event.

What Went Well

Full environment snapshots before change
Controlled shutdown of all vCenters
GSS oversight during execution
Clear sequencing of unregister and replication steps

What Required Attention

A few things stood out post-change:

Certificate references still pointed to the original site
Additional certificate regeneration was required
Replication topology had to be validated manually

This is typical.

Breaking ELM solves the primary problem, but secondary cleanup work is almost always required.

Important note:
This work addressed the deprecated cross-instance ELM configuration and removed the immediate architectural blocker. That said, ELM will still need to be removed before the affected vCenters are upgraded to vCenter 9.0.

Validation

After separation:

All vCenters powered on successfully
Services were verified via service-control checks
SDDC Managers were accessible and functional
No UI instability (no “spinning circle” issues)
Replication topology confirmed healthy

From an operations perspective, this is the real success criteria—not just command completion.

Lessons Learned

This scenario reinforces several patterns that show up repeatedly in VCF environments.

1. Functional Does Not Mean Supported

The environment was stable before the change.

That didn’t make it upgradeable.

2. ELM Creates Real Architectural Coupling

This wasn’t just shared visibility. It was:

Shared identity
Shared replication
Shared failure domain

That coupling is what made the upgrade path invalid.

3. Breaking ELM Is a Multi-Layer Operation

You’re not just removing links—you’re modifying:

SSO domain membership
vmdir replication agreements
Certificate relationships
Service dependencies

Each layer needs to be addressed.

4. Replication Topology Matters More Than Most Realize

One thing that often surprises teams is how critical replication design is.

After unlinking:

You must explicitly rebuild a valid topology
Ring structures are commonly used
Validation is not optional

5. Cleanup Work Is Inevitable

Even after a successful separation:

Certificates may need regeneration
Residual references may exist
Additional change windows may be required

Plan for that upfront.

Conclusion

This wasn’t a lifecycle failure. It was an architectural correction.

The upgrade blocker wasn’t a version mismatch or a failed precheck—it was a legacy topology that no longer aligned with supported VCF design.

Breaking Enhanced Linked Mode between two VCF instances required:

Controlled shutdown and protection of all nodes
CMS-based removal of SSO relationships
Reconfiguration of vmdir replication
Careful validation of platform health afterward

From an operations perspective, the takeaway is simple:

Always validate the architecture before starting an upgrade.

Because sometimes the most important step in an upgrade isn’t applying a patch.

It’s removing a dependency that shouldn’t exist anymore.
